Positioner L8A-100RDiPL

L8A-100RDM L8A-100LSMNon feedback type electrical valve positioner

The L8A-100RDiPL angle stroke feedback pneumatic control valve positioner L8A-100 series electrical valve positioner is a device that receives a 4-20mA DC current signal from the control system and adjusts the valve opening through a pneumatic actuator. The valve positioner comes with an air filter pressure reducing valve, which displays the on-site valve position opening (percentage) and outputs feedback signals (4~20mA). Simply connect compressed air with a pressure range of 5~10kgf/cm2 to the SUP input interface of the positioner. The feedback type valve positioner is equipped with an LCD screen display, which can clearly see the input and output opening signals.
L8A-100RDiPL angle stroke feedback pneumatic control valve positioner L8A-100 series electrical valve positioner technical parameters:
1. Valve positioner model:
L8A-100RDiPL with angular travel feedback, L8A-100RDM without angular travel feedback;
Linear travel with feedback L8A-100LSiPL, angular travel without feedback L8A-100LSM;
2. Input signal: 4~20mA DC;
3. Impedance: 250 ± 15 Ω (without feedback model);
4. Supply pressure: 1.4~7.0kgf/cm2 (20~100psi);
5. Travel: Straight travel of 10-150mm, angular travel of 0-90 °;
6. Interface size: Gas source interface PT (NPT) 1/4, pressure gauge interface PT (NPT) 1/4, power supply interface PF1/2 (G1/2);
7. Explosion proof rating: ExiaICT6, IP65;
8. Environmental temperature: working temperature standard model -20 ° C~+60 ° C;
9. Linear: ± 1.0% F.S;
10. Lag: 1.0% F.S;
11. Sensitivity: single action ± 0.2% F.S, double action ± 0.5% F.S;
12. Repeatability: ± 0.5% F.S;
13. Air consumption: 3LPM (Sup=1.4kgf/cm2,20psi);
14. Flow rate: 80LPM (Sup=1.4kgf/cm2,20psi);
15. Repeatability: ± 0.5% F.S;
16. Shell material weight: die cast aluminum, weighing 2.5kg;


L8A-100 series electrical valve positioner with number display function technical parameters:
1. Input signal: 4-20mA DC (two-wire system);
2. Input load voltage: MAX 15V;
3. Feedback signal: 4-20mA DC (two-wire system);
4. Feedback signal power supply: DC24V ± 15%;
